Motor Division
Property
|
U. V. W (AWG22 WIRE) |
||
|
U = White wire |
V = Red wire |
W = Blue wire |
|
H1, H2, H3, GND, 5V (AWG 28 WIRE) |
||||
|
H1 = Red |
H2 = Yellow |
H3 = Blue |
GND = Black |
5V= White |
product selection methods, and specifications
Motor Selection Example)
When selecting a 30W motor for a front bracket square, indicate as PW08-DC02445-3008-K03ZS.
For motors ranging from 30W to 70W: output shaft outer diameter Ø8 FIX.
For motors above 80W: Ø8 or Ø10 can be selected based on customer requirements.
